Temporisateur modulaire universel
- Basé sur un microcontrôleur
- 10 fonctions
- 10 plages de temps (1s,10s,1m,10m,1h,10h,1d,10d,ON,OFF)
- 1 contact inverseur
- Indication LED pour l’alimentation et l’état du relais
- Montage sur rail
TEMPORISATEURS MODULAIRES
| Supply terminals | A1,A2 |
| Pulse terminal | S |
| Supply voltage | AC/DC 12-240V |
| Rated frequency | 50/60Hz |
| Time range | 0.1 s-10days |
| Setting accuracy | <5% |
| Repetition accuracy | <0.2% |
| Output contacts | 1 C/0 |
| Current rating | 8A /AC1 |
| Contacts capacity | AC-15: 2A |
| Insulation voltage | 250V |
| Protection degree | IP20 |
| Pollution degree | 3 |
| Electrical life | 105 |
| Mechanical life | 106 |
| Altitude | ≤2000m |
| Ambient temperature | -5℃~+40℃ |
| Storage temperature | -10℃~+50℃ |
| Wire size | 0.5mm2~1 mm2 |
| Torque | 0.5Nm |
| Mounting | TH-35 DIN-Rail |
