| REFERENCE | NDR12012 | NDR12024 |
| OUTPUT | ||
| DC VOLTAGE | 12V | 24V |
| CURRENT CURRENT | 10A | 5A |
| CURRENT RANGE | 0~10A | 0~5A |
| RATED POWER | 120W | 120W |
| RIPPLE & NOISE | 100mVp-p | 120mVp-p |
| VOLTAGE ADJ. RANGE | 12~14V | 24~48V |
| VOLTAGE TOLERANCE | ±2.0% | ±1.0% |
| LINE REGULATION | ±0.5% | ±0.5% |
| LOAD REGULATION | ±1.0% | ±1.0% |
| INPUT | ||
| VOLTAGE RANGE | 90~264VAC 127~370VDC | |
| [DC input operation possible by connecting AC/L(+),AC/N(-)] | ||
| FREQUENCY RANGE | 47~63Hz | |
| EFFICIENCY | 85.50% | 88% |
| AC CURRENT | 2.25A/115VAC 1.3A/230VAC | |
| INRUSH CURRENT | 20A/115VAC 35A/230VAC | |
| LEAKAGE CURRENT | <1MA/240VAC | |
| PROTECTION | ||
| OVERLOAD | 105~130% rated output power | 105~130% rated output power |
| Protection type: Constant current limiting, | Protection type: Constant current limiting, | |
| recovers automatically after fault condition is removed | recovers automatically after fault condition is removed | |
| OVER VOLTAGE | 14~17V | 29~33V |
| Protection type: Shut down o/p voltage, re-power on to recover | Protection type: Shut down o/p voltage, re-power on to recover | |
| OVER TEMPERATURE | Protection type: Shut down o/p voltage, re-power on to recover | Protection type: Shut down o/p voltage, re-power on to recover |
